Harley-Davidson FXS Softail Blackline, 2012





Harley-Davidson FXS Softail Blackline, 2012

USA Specifications/Technical Details

The Dimensions
Length 93 in. (2362 mm)
Overall Width 34 in. (864 mm)
Overall Height 47.3 in. (1201 mm)


Seat Height:
- Laden2 24 in. (610 mm)
- Unladen 26.1 in. (663 mm)
Ground Clearance 5.25 in. (133 mm)
Rake (steering head) 30°
Fork Angle 33.5°
Trail 4.84 in. (123 mm)
Wheelbase 66.5 in. (1689 mm)

Tires (Dunlop® Harley-Davidson® Series, blackwall):
- Front – D402F MH90-21 54H
- Rear – D402 MU85B16 77H
Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 3.5 qts. (3.3 L)
Transmission Capacity 1.0 qt. (.95 L)
Primary Chain
Case Capacity 1.0 qt. (.95 L)

Weight:
- As Shipped 638.5 lbs. (290 kg)
- In Running Order 682.5 lbs. (310 kg)
- Gross Vehicle Weight Rating 1124 lbs. (510 kg)
- Gross Axle Weight Rating:
- Front 414 lbs. (188 kg)
- Rear 710 lbs. (322 kg)

The Engine
Engine Air-cooled, Twin Cam 103BTM
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Bore x Stroke 3.875 in. x 4.38 in. (98.4 mm x 111.1 mm)
Displacement 103 cu. in. (1690 cc)
Compression Ratio 9.6:1
Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Paper, washable
Lubrication System Pressurized, dry-sump

The Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

The Chassis
Frame Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, round tube sections, forged junctions; MIG welded
Front Forks 41.3 mm telescopic
Rear Shocks Hidden, horizontal-mounted, coil-over
Wheels4: Black Anodized Aluminum Profile Laced
- Front 21 in. x 2.15 in. (533 mm x 55 mm)
- Rear 16 in. x 3 in. (406 mm x 76 mm)

Brakes:
- Caliper Type 4-piston front and 2-piston rear
- Rotor Type (diameter x width): Patented, uniform expansion rotors
- Front 11.5 in. x .2 in. (292 mm x 5.1 mm)
- Rear 11.5 in. x .23 in. (292mm x 5.8 mm)
- Anti-lock Braking System: Available

Suspension Travel:
- Front Wheel 5.6 in. (143 mm)
- Rear Wheel 3.6 in. (91 mm)

The Performance
Engine Torque5 (per J1349):
- North America 98.7 ft. lbs. @ 3250 RPM (134 Nm @ 3250 RPM)
Lean Angle (per J1168):
- Right 24.4°
- Left 25.9°

Fuel Economy6 (EPA urban/highway test) 42 mpg (5.6 L/100 km)

COLOR OPTIONS
Solids
- Vivid Black
- Black Denim
Two-Tones
- Big Blue Pearl/Vivid Black
- H-D Orange/Vivid Black

U.S. MSRP
Vivid Black $15,499
Color $15,884
Two-Tone $15,999

The Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 38-amp system (439W @ 13V, 2000 RPM, 489W max power @ 13V)
Starting 1.2 kW electric with solenoid shift starter motor engagement

The Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Turn Signal Lights 28W (21W) self-canceling
- Rear Tail/Stop/Turn Signal Lights 8W/28W (5W/21W) self-canceling
- Indicator Lamps: High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system7 (optional), 6-speed, low
fuel warnings

Warranty
Warranty8 24 months (unlimited mileage)
Service Interval9 First 1000 miles (1600 km), every 5000 miles (8000 km) thereafter

1.  Vehicles depicted may differ from vehicles manufactured and delivered. Specifications and prices listed may differ from specifications and prices of vehicles manufactured and delivered. All product descriptions (including depictions, specifications, dimensions, measurements, ratings and competitive comparisons) are based on available information at the time of publication.

Though such descriptions are believed correct, errors and changes can occur and complete accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and specifications, and may change or discontinue models, without notice and without incurring any obligation. Attention: Vehicles in the configurations shown and many of the accessories described in this catalog may not be available for sale or use in some locations. Please check with your dealer for complete product details and the latest information. All models feature 6-speed transmission (V-Rod® models and Sportster® models are 5-speed) and carbon fiber belt final drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2.   Measurement reflects 180 lb. (81.7 kg) operator weight.
3.   Recommended 91 octane or higher fuel (R+M)/2.
4.   Standard and optional wheels may vary by country and region.
5.   Values shown are nominal. Performance may vary by country and region.
6.  The combined fuel economy numbers were derived using a combination of estimated city and highway values. Fuel economy estimates are derived from US EPA exhaust emission certification data on a sample motorcycle from the corresponding family under ideal laboratory conditions. Your actual fuel economy will vary depending on your personal riding habits, road and driving conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7.  North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
8.  See motorcycle owner’s manual for complete details.
9.  Inspections of certain systems and components are required at 2500 mile (4000 km) intervals. See Owner’s Manual for full details.

Read More

Harley-Davidson FLSTN Softail Deluxe, 2012





Harley-Davidson FLSTN Softail Deluxe, 2012

USA Specifications
Dimensions
Length 94.7 in. (2405 mm)
Overall Width 38.6 in. (980 mm)
Overall Height 44.3 in. (1125 mm)

Seat Height:
- Laden2 24.5 in. (622 mm)
- Unladen 25.9 in. (658 mm)
Ground Clearance 4.8 in. (122 mm)
Rake (steering head) 32.1°
Fork Angle 32°
Trail 5.8 in. (147 mm)
Wheelbase 64.5 in. (1638 mm)

Tires (Dunlop® Harley-Davidson® Series, wide whitewall):
- Front – D402F MT90-16 72H
- Rear – D402 MU85B16 77H
Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 3.5 qts. (3.3 L)
Transmission Capacity 1.0 qt. (.95 L)
Primary Chain
Case Capacity 1.0 qt. (.95 L)

Weight:
- As Shipped 695 lbs. (315.0 kg)
- In Running Order 726 lbs. (329.0 kg)
- Gross Vehicle Weight Rating 1160 lbs. (526.0 kg)
- Gross Axle Weight Rating:
- Front 430 lbs. (195.0 kg)
- Rear 730 lbs. (331.0 kg)

Engine
Engine Air-cooled, Twin Cam 103BTM
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Bore x Stroke 3.875 in. x 4.38 in. (98.4 mm x 111.1 mm)
Displacement 103 cu. in. (1690 cc)
Compression Ratio 9.6:1
Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Paper, washable
Lubrication System Pressurized, dry-sump

Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

Chassis
Frame Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, round tube sections, forged junctions; MIG welded
Front Forks 41.3 mm telescopic, “beer can” covers
Rear Shocks Hidden, horizontal-mounted, coil-over
Wheels4 (Tubeless Chrome Aluminum Profile Laced option): Steel Laced
- Front 16 in. x 3 in. (406 mm x 76 mm)
- Rear 16 in. x 3 in. (406 mm x 76 mm)

Brakes:
- Caliper Type 4-piston front and 2-piston rear
- Rotor Type (diameter x width): Patented, uniform expansion rotors
- Front 11.5 in. x .2 in. (292 mm x 5.1 mm)
- Rear 11.5 in. x .23 in. (292 mm x 5.8 mm)
- Anti-lock Braking System: Available

Suspension Travel:
- Front Wheel 5.1 in. (130 mm)
- Rear Wheel 3.6 in. (91 mm)

Performance
Engine Torque5 (per J1349):
- North America 98.7 ft. lbs. @ 3000 RPM (134 Nm @ 3000 RPM)
Lean Angle (per J1168):
- Right 25.8°
- Left 26.7°

Fuel Economy6 (EPA urban/highway test) 42 mpg (5.6 L/100 km)

Color Options
Solids
- Vivid Black
- Big Blue Pearl
- Ember Red Sunglo
Two-Tones
- Birch White/Sunburst Red
- Birch White/Midnight Pearl
Custom Colors
- Tequila Sunrise/H-D Orange

U.S. MSRP
Vivid Black $17,149
Solids $17,534
Two-Tones $17,854
Custom Colors $18,024

Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 38-amp system (439W @ 13V, 2000 rpm, 489W max power @ 13V)
Starting 1.2 kW electric with solenoid shift starter motor engagement

The Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Tail/Stop Lights 8W/28W (5W/21W)
- Turn Signal Lights 28W (21W) self-canceling
- Indicator Lamps: High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system7 (optional), 6-speed, low fuel warnings

Harley-Davidson FLSTN Softail Deluxe Model Highlights

New Rigid-mounted, counter-balanced Twin Cam 103B™ V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI)
New Tubeless Chrome Aluminum Profile Laced wheel option
New Paint color options
- Fuel tank sender for accurate fuel-level readings
- Black powder-coated powertrain with chrome covers
- Chrome over/under shotgun exhaust
- Chrome, Laced Steel wheels
- Wide whitewall tires
- MU85B-16 rear tire
- Chrome nostalgic seven-inch ball headlamp
- Chrome oil tank
- Chrome nostalgic tank console with electronic speedometer
- Stainless steel, low-rise handlebar
- Full-length rider footboards
- Two-piece, two-up Softail® seat with “collapsing” sides and removable pillion and chrome grab rails
- Integrated chrome luggage rack
- Tombstone taillight
- Full-coverage front and rear fenders with chrome accents

Key Features and Benefits
- 6-Speed Cruise Drive® Transmission
- Horseshoe oil tank
- Five-gallon fuel tank
- Optional Chrome Profile Laced Aluminum wheels
- Optional Original Equipment Custom Color paint program

Read More

Harley-Davidson FLSTFB Softail Fat Boy Lo, 2012





Harley-Davidson FLSTFB Softail Fat Boy Lo, 2012

USA Specifications

Dimensions
Length 94.3 in. (2395 mm)
Overall Width 39.0 in. (990 mm)
Overall Height 43.1 in. (1095 mm)


Seat Height:
- Laden2 24.3 in. (616 mm)
- Unladen 26.4 in. (669 mm)
Ground Clearance 4.8 in. (122 mm)
Rake (steering head) 31.6°
Fork Angle 31.6°
Trail 5.8 in. (147 mm)
Wheelbase 64.5 in. (1638 mm)

Tires (Dunlop® Harley-Davidson® Series, radial blackwall front and rear):
- Front – D408F 140/75R17 67V
- Rear – D407 200/55R17 78V
Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 3.5 qts. (3.3 L)
Transmission Capacity 1.0 qt. (.95 L)
Primary Chain
Case Capacity 1.0 qt. (.95 L)

Weight:
- As Shipped 700 lbs. (318.0 kg)
- In Running Order 731 lbs. (332.0 kg)
- Gross Vehicle Weight Rating 1160 lbs. (526.0 kg)
- Gross Axle Weight Rating:
- Front 430 lbs. (195.0 kg)
- Rear 730 lbs. (331.0 kg)

Engine
Engine Air-cooled, Twin Cam 103BTM
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Bore x Stroke 3.875 in. x 4.38 in. (98.4 mm x 111.1 mm)
Displacement 103 cu. in. (1690 cc)
Compression Ratio 9.6:1
Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Paper, washable
Lubrication System Pressurized, dry-sump

Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

The Chassis
Frame Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, round tube sections, forged junctions; MIG welded
Front Forks 41.3 mm telescopic, “beer can” covers
Rear Shocks Hidden, horizontal-mounted, coil-over
Wheels4: Black Bullet Hole Cast Aluminum Disc
- Front 17 in. x 3.5 in. (432 mm x 89 mm)
- Rear 17 in. x 6 in. (432 mm x 152 mm)


Brakes:
- Caliper Type 4-piston front and 2-piston rear
- Rotor Type (diameter x width): Patented, uniform expansion rotors
- Front 11.5 in. x .2 in. (292 mm x 5.1 mm)
- Rear 11.5 in. x .23 in. (292 mm x 5.8 mm)
- Anti-lock Braking System: Available

Suspension Travel:
- Front Wheel 5.1 in. (130 mm)
- Rear Wheel 3.6 in. (91 mm)

Performance
Engine Torque5 (per J1349):
- North America 98.7 ft. lbs. @ 3000 RPM (134 Nm @ 3000 RPM)
Lean Angle (per J1168):
- Right 25.6°
- Left 25.2°

Fuel Economy6 (EPA urban/highway test) 42 mpg (5.6 L/100 km)

COLOR OPTIONS
Solids
- Vivid Black
- Big Blue Pearl
- Brilliant Silver Pearl
- Black Denim

U.S. MSRP
Vivid Black $16,649
Solids $17,034

The Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 38-amp system (439W @ 13V, 2000 rpm, 489W max power @ 13V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Tail/Stop Lights 8W/28W (5W/21W)
- Turn Signal Lights 28W (21W) self-canceling
- Indicator Lamps: High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system7 (optional), 6-speed, low fuel warnings

Read More

Harley-Davidson FLSTF Softail Fat Boy, 2012



Harley-Davidson FLSTF Softail Fat Boy, 2012

USA Specifications/Technical Details

Dimensions
Length 94.3 in. (2395 mm)
Overall Width 39.0 in. (990 mm)
Overall Height 43.1 in. (1095 mm)

Seat Height:
- Laden2 25.0 in. (635 mm)
- Unladen 27.1 in. (690 mm)
Ground Clearance 5.1 in. (130 mm)
Rake (steering head) 31°
Fork Angle 31°
Trail 5.8 in. (147 mm)
Wheelbase 64.5 in. (1638 mm)

Tires (Dunlop® Harley-Davidson® Series, radial blackwall front and rear):
- Front – D408F 140/75R17 67V
- Rear – D407 200/55R17 78V

Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 3.5 qts. (3.3 L)
Transmission Capacity 1.0 qt. (.95 L)
Primary Chain
Case Capacity 1.0 qt. (.95 L)

Weight:

• - As Shipped 694 lbs. (315.0 kg)
• - In Running Order 725 lbs. (329.0 kg)
• - Gross Vehicle Weight Rating 1160 lbs. (526.0 kg)
• - Gross Axle Weight Rating:
• - Front 430 lbs. (195.0 kg)
• - Rear 730 lbs. (331.0 kg)

Engine

• Engine Air-cooled, Twin Cam 103BTM
• Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
• Bore x Stroke 3.875 in. x 4.38 in. (98.4 mm x 111.1 mm)
• Displacement 103 cu. in. (1690 cc)
• Compression Ratio 9.6:1
• Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
• Air Cleaner Paper, washable
• Lubrication System Pressurized, dry-sump

Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

The Chassis
Frame Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, round tube sections, forged junctions; MIG welded
Front Forks 41.3 mm telescopic, “beer can” covers
Rear Shocks Hidden, horizontal-mounted, coil-over
Wheels4 (Polished Chrome Aluminum Bullet Hole Disc front and rear option):
Silver Cast Aluminum Bullet Hole Disc
- Front 17 in. x 3.5 in. (432 mm x 89 mm)
- Rear 17 in. x 6 in. (432 mm x 152 mm)
Brakes:
- Caliper Type 4-piston front and 2-piston rear
- Rotor Type (diameter x width): Patented, uniform expansion rotors
- Front 11.5 in. x .2 in. (292 mm x 5.1 mm)
- Rear 11.5 in. x .23 in. (292 mm x 5.8 mm)
- Anti-lock Braking System: Available

Suspension Travel:
- Front Wheel 5.1 in. (130 mm)
- Rear Wheel 4.3 in. (109 mm)

Performance
Engine Torque5 (per J1349):
- North America 98.7 ft. lbs. @ 3000 RPM (134 Nm @ 3000 RPM)
Lean Angle (per J1168):
- Right 26.2°
- Left 27°

The Fuel Economy6 (EPA urban/highway test) 42 mpg (5.6 L/100 km)

COLOR OPTIONS
Solids
- Vivid Black
- Chrome Yellow
Two-Tones
- Midnight Pearl/Brilliant Silver Pearl
Custom Colors
- Tequila Sunrise/H-D Orange

U.S. MSRP
Vivid Black $16,349
Solids $16,734
Two-Tones $17,054
Custom Colors $17,224

Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 38-amp system (439W @ 13V, 2000 rpm, 489W max power @ 13V)
Starting 1.2 kW electric with solenoid shift starter motor engagement

Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Tail/Stop Lights 8W/28W (5W/21W)
- Turn Signal Lights 28W (21W) self-canceling
- Indicator Lamps: High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system7 (optional), 6-speed, low fuel warnings

The Harley-Davidson FLSTF Softail Fat Boy Model Highlights

NEW Rigid-mounted, counter-balanced Twin Cam 103B™ V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI)
NEW Low profile, 1.25-inch internally-wired handlebar
NEW Paint color options
- Security Package option including factory-installed Harley-Davidson® Smart Security System with hands-free fob and Anti-Lock Braking System (ABS)
- Hand controls with fewer wires
- Odometer trip switch
- Single button hazzard warning
- Large odometer readout with gear and RPM display
- Fuel tank sender for accurate fuel-level readings
- Black powder-coated powertrain with chrome covers
- Chrome over/under shotgun exhaust
- Silver, Bullet Hole Disc Cast Aluminum wheels
- 200 mm rear tire
- Chrome front fork nacelle
- Chrome nostalgic seven-inch ball headlamp
- Chrome oil tank
- Chrome tank console with electronic speedometer
- Chrome bullet-studded seat valance and tank strap
- Chrome 1.25-inch, internally-wired handlebar and Bare Knuckle risers
- Full-size rider footboards
- Two-piece, two-up Softail® seat with removable pillion
- Custom trimmed front fender

Read More

Harley-Davidson FLSTC Heritage Softail Classic, 2012





Harley-Davidson FLSTC Heritage Softail Classic, 2012



Model Highlights
NEW Rigid-mounted, counter-balanced Twin Cam 103B V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI)
NEW Tubeless Chrome Aluminum Profile Laced wheel option
NEW Paint color options
- Fuel tank sender for accurate fuel-level readings
- Black powder-coated powertrain with chrome covers
- Chrome exhaust with dual staggered shorty mufflers
- Chrome, Laced Steel wheels with chrome hub covers
- 150 mm rear tire
- Chrome nostalgic seven-inch ball headlamp
- Chrome directional light bar and passing lamps
- Chrome oil tank
- Chrome nostalgic “cats-eye” tank console with a retro speedometer face
- Two-tone leather tank panel with matching sissy-bar backrest trim
- Ergonomic stainless steel, classic touring handlebar
- Half-round footboards and oval brake pedal pad
- Two-piece, two-up Softail seat with removable pillion
- Studded, nostalgic leather saddlebags with hidden quick-detach buckles
- Detachable king-size Lexan clear windshield
- Full-coverage front and rear fenders with chrome accents

Key Features and Benefits
- 6-Speed Cruise Drive Transmission
- Horseshoe oil tank
- Five-gallon fuel tank
- Optional Tubeless Chrome Aluminum Profile Laced wheels
- Optional Original Equipment Custom Color Paint Program

USA Specifications

Dimensions
Length 94.5 in. (2400 mm)
Overall Width 37.6 in. (955 mm)
Overall Height 55.2 in. (1402 mm)


Seat Height:
- Laden2 25.5 in. (648 mm)
- Unladen 27.1 in. (688 mm)
Ground Clearance 5.1 in. (130 mm)
Rake (steering head) 31°
Fork Angle 31°
Trail 5.8 in. (147 mm)
Wheelbase 64.5 in. (1638 mm)

Tires (Dunlop® Harley-Davidson® Series, bias blackwall front and rear):
- Front – D402F MT90B16 72H
- Rear – D401 150/80B16 71H
Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 1.0 gal.)
Oil Capacity (w/filter) 3.5 qts. (3.3 L)
Transmission Capacity 1.0 qt. (.95 L)
Primary Chain
Case Capacity 1.0 qt. (.95 L)

Weight:
- As Shipped 730 lbs. (331.0 kg)
- In Running Order 761 lbs. (345.0 kg)
- Gross Vehicle Weight Rating 1160 lbs. (526.0 kg)
- Gross Axle Weight Rating:
- Front 430 lbs. (195.0 kg)
- Rear 730 lbs. (331.0 kg)

Engine
Engine Air-cooled, Twin Cam 103BTM
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Bore x Stroke 3.875 in. x 4.38 in. (98.4 mm x 111.1 mm)
Displacement 103 cu. in. (1690 cc)
Compression Ratio 9.6:1
Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Paper, washable
Lubrication System Pressurized, dry-sump

Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

Chassis
Frame Mild steel tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, round tube sections, forged junctions; MIG welded
Front Forks 41.3 mm telescopic, “beer can” covers
Rear Shocks Hidden, horizontal-mounted, coil-over


Wheels4 (Tubeless Chrome Aluminum Profile Laced option):
Steel Laced
- Front 16 in. x 3 in. (406 mm x 76 mm)
- Rear 16 in. x 3 in. (406 mm x 76 mm)

Brakes:
- Caliper Type 4-piston front and 2-piston rear
- Rotor Type (diameter x width): Patented, uniform expansion rotors
- Front 11.5 in. x .2 in. (292 mm x 5.1 mm)
- Rear 11.5 in. x .23 in. (292 mm x 5.8 mm)
- Anti-lock Braking System: Available

Suspension Travel:
- Front Wheel 5.1 in. (130 mm)
- Rear Wheel 4.3 in. (109 mm)

Performance
Engine Torque5 (per J1349):
- North America 96.9 ft. lbs. @ 3000 RPM (131 Nm @ 3000 RPM)
Lean Angle (per J1168):
- Right 24.4°
- Left 25.9°

Fuel Economy6 (EPA urban/highway test) 42 mpg (5.6 L/100 km)

COLOR OPTIONS
Solids
- Vivid Black
- Big Blue Pearl
- White Hot Pearl
Two-Tones
- Ember Red Sunglo/Merlot Sunglo
- Midnight Pearl/Brilliant Silver Pearl
Custom Colors
- Tequila Sunrise/H-D Orange

U.S. MSRP
Vivid Black $17,349
Solids $17,734
Two-Tones $18,054
Custom Colors $18,224

Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 38-amp system (439W @ 13V, 2000 rpm, 489W max power @ 13V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Tail/Stop Lights 8W/28W (5W/21W)
- Turn Signal Lights 28W (21W) self-canceling
- Indicator Lamps: High beam, front fender running lights, neutral, low oil pressure, turn signals, engine diagnostics, security system7
(optional), 6-speed, low fuel warnings

Warranty
Warranty8 24 months (unlimited mileage)
Service Interval9 First 1000 miles (1600 km), every 5000 miles (8000 km) thereafter

Read More

Harley-Davidson FXDWG Dyna Wide Glide, 2012





Harley-Davidson FXDWG Dyna Wide Glide, 2012

Model Highlights

NEW Rubber-mounted Twin Cam 103 V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI), rated at 100 ft. lbs. of torque
NEW Optional Security Package bundling Anti-lock Braking System (ABS) and a Smart Security System for greater value


The Paint color options
- Black powder-coated powertrain with chrome covers
- Chrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
- 4.7-gallon Street Bob®-style fuel tank, raised at the front .75-inch
- 40-spoke laced steel wheels with black rims
- 21-inch front wheel
- Front and rear suspension lowered one inch
- 34 degree fork angle
- Wide polished aluminum triple clamps
- Chopped rear fender with chrome supports
- Low solo seat with separate passenger pillion
- Stainless steel internally-wired handlebar on four-inch black riser
- Wrinkle-black battery box and fender struts
- Black mirrors and headlight bucket
- Black one-piece wire sissy bar
- Dual red LED lights combine the stop/turn/tail functions
- Side-mounted license plate
- Low-profile tank console with electronic speedometer

Features and Benefits
- NEW Rubber-mounted Twin Cam103™ V-Twin engine
- 6-speed Cruise Drive® transmission
- Exposed under-seat battery box
- Exposed rear coil-over shock absorbers
- Forward-mounted rider footpegs with brake and shift levers
- Optional Harley-Davidson® Smart Security System with hands-free security fob

USA Specifications

US MSRP Price: Vivid Black $14,849, Two-Tones $15,554 USD

Dimensions
Length 94.0 in. (2388 mm)
Overall Width 37.2 in. (945 mm)
Overall Height 47.8 in. (1214 mm)
Seat Height:
- Laden2 25.5 in. (648 mm)
- Unladen 26.7 in. (678 mm)
Ground Clearance 4.2 in. (107 mm)
Rake (steering head) 34°
Fork Angle 36°
Trail 5.2 in. (132 mm)
Wheelbase 68.3 in. (1735 mm)

Tires (Michelin® Scorcher® “31” front and rear):
- Front – Scorcher® “31” 80/90-21 54H
- Rear – Scorcher® “31” 180/60B17 75V
Fuel Capacity 4.7 gal. (17.8 L) (warning light at approximately 0.9 gal.)
Oil Capacity (w/filter) 3.0 qts. (2.8 L)
Transmission Capacity 1.0 qt. (.95 L)
Primary Chain
Case Capacity 1.0 qt. (.95 L)

Weight:
- As Shipped 650 lbs. (295.0 kg)
- In Running Order 668 lbs. (303.0 kg)
- Gross Vehicle Weight Rating 1085 lbs. (492.2 kg)
- Gross Axle Weight Rating:
- Front 390 lbs. (176.9 kg)
- Rear 695 lbs. (315.3 kg)

The Engine
Engine Air-cooled, Twin Cam 103
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Bore x Stroke 3.875 in. x 4.38 in. (98.4 mm x 111.3 mm)
Displacement 103 cu. in. (1690 cc)
Compression Ratio 9.6:1
Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Fiberglass Media, washable
Lubrication System Pressurized, dry-sump

The Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

The Chassis
Frame Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, rectangular tube sections, stamped junctions; MIG welded
Front Forks 49 mm with polished aluminum fork triple clamp and dual-rate springs
Rear Shocks Coil-over shock

Wheels4: Black Steel Laced
- Front 21 in. x 2.15 in. (533 mm x 55 mm)
- Rear 17 in. x 4.5 in. (432 mm x 114 mm)

Brakes:
- Caliper Type 4-piston front, and 2-piston torque-free floating rear
- Rotor Type (diameter x width): Patented, uniform expansion rotors (floating, front only)
- Front (floating) 11.8 in. x .2 in. (300 mm x 5.1 mm)
- Rear 11.5 in. x .23 in. (292 mm x 5.8 mm)
- Anti-lock Braking System: Available

Suspension Travel:
- Front Wheel 5 in. (127 mm)
- Rear Wheel 3.1 in. (78.74 mm)

Performance
Engine Torque5 (per J1349):
- North America 100 ft. lbs. @ 3500 RPM (136 Nm @ 3500 RPM)
Lean Angle (per J1168):
- Right 28.4°
- Left 31.9°

Fuel Economy6 (EPA urban/highway test) 42 mpg (5.6 L/100 km)

COLOR OPTIONS
Solids
- Vivid Black
Two-Tones
- Vivid Black with Flames
- Big Blue Pearl with Flames
- Ember Red Sunglo with Flames

U.S. MSRP
Vivid Black $14,849
Two-Tones $15,554

The Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 40-amp system (493W @ 13.5V, 2000 rpm, 540W max power @ 13.5V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Rear Turn Signal Lights 9W/43W self-canceling
- Indicator Lamps: High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system7 (optional), 6-speed, low fuel warnings

Warranty
Warranty8 24 months (unlimited mileage)
Service Interval9 First 1000 miles (1600 km), every 5000 miles (8000 km) thereafter

1.  Vehicles depicted may differ from vehicles manufactured and delivered.Specifications and prices listed may differ from specifications and prices of vehicles manufactured and delivered. All product descriptions (including depictions, specifications, dimensions, measurements, ratings and competitive comparisons) are based on available information at the time of publication. Though such descriptions are believed correct, errors and changes can occur and complete accuracy cannot be guaranteed. Harley-Davidson may make changes at any time to prices and specifications, and may change or discontinue models, without notice and without incurring any obligation. Attention: Vehicles in the configurations shown and many of the accessories described in this catalog may not be available for sale or use in some locations. Please check with your dealer for complete product details and the latest information. All models feature 6-speed transmission (V-Rod® models and Sportster models are 5-speed) and carbon fiber belt final drive; multi-plate clutch with diaphragm spring in oil bath; and 2-year unlimited mileage warranty.
2.  Measurement reflects 180 lb. (81.7 kg) operator weight.
3.  Recommended 91 octane or higher fuel (R+M)/2.
4.  Standard and optional wheels may vary by country and region.
5.  Values shown are nominal. Performance may vary by country and region.
6.  The combined fuel economy numbers were derived using a combination of estimated city and highway values. Fuel economy estimates are derived from US EPA exhaust emission certification data on a sample motorcycle from the corresponding family under ideal laboratory conditions. Your actual fuel economy will vary depending on your personal riding habits, road and driving conditions, vehicle condition and maintenance, tire pressure, vehicle configuration (parts and accessories), and vehicle loading (cargo, rider and passenger weight). Break-in mileage may vary.
7.  North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
8.  See motorcycle owner’s manual for complete details.
9.  Inspections of certain systems and components are required at 2500 mile (4000 km) intervals. See Owner’s Manual for full details.

Read More

Harley-Davidson FXDF Dyna Fat Bob, 2012





Harley-Davidson FXDF Dyna Fat Bob, 2012

Model Highlights
NEW Optional Security Package bundling Anti-lock Braking System (ABS) and a Smart Security System for greater value
NEW Rubber-mounted Twin Cam103 V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI), rated at 92 ft. lbs. of torque


NEW Paint color options
- Black powder-coated powertrain with polished covers
- Chrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
- 5-gallon Fat Bob fuel tank
- Silver, Slotted Disc Cast Aluminum wheels
- Sport front fender with painted brace supports
- Bobtail rear fender with chrome supports
- One-piece, two-up Dyna classic seat
- Stainless steel drag-style handlebar on black riser
- Black fork lowers and mirrors
- Polished aluminum triple clamps
- High-performance, chrome-covered, coil-over rear shocks
- Chrome low-profile tank console with electronic speedometer
- Twin chrome headlamps

Features and Benefits
- NEW Rubber-mounted Twin Cam103 V-Twin engine
- 6-speed Cruise Drive® transmission
- Exposed under-seat battery box
- Forward-mounted rider footpegs with brake and shift levers
- Optional Harley-Davidson® Smart Security
System with hands-free security fob

USA Specifications
Dimensions
Length 91.7 in. (2329 mm)
Overall Width 35.0 in. (889 mm)
Overall Height 44.5 in. (1130 mm)


Seat Height:
- Laden2 26.1 in. (663 mm)
- Unladen 27.0 in. (686 mm)
Ground Clearance 4.9 in. (125 mm)
Rake (steering head) 29°
Fork Angle 28°
Trail 4.9 in. (125 mm)
Wheelbase 63.7 in. (1618 mm)

Tires (Dunlop® Harley-Davidson® Series, bias blackwall front and rear):
- Front – D427F 130/90B16 67H
- Rear – D427 180/70B16 77H
Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 0.9 gal.)
Oil Capacity (w/filter) 3.0 qts. (2.8 L)
Transmission Capacity 1.0 qt. (.95 L)


Primary Chain
Case Capacity 1.0 qt. (.95 L)

Weight:

• - As Shipped 673 lbs. (305.0 kg)
• - In Running Order 706 lbs. (320.0 kg)
• - Gross Vehicle Weight Rating 1085 lbs. (492.2 kg)
• - Gross Axle Weight Rating:
• - Front 390 lbs. (176.9 kg)
• - Rear 695 lbs. (315.3 kg)

Engine

• Engine Air-cooled, Twin Cam 103
• Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
• Bore x Stroke 3.875 in. x 4.38 in. (98.4 mm x 111.3 mm)
• Displacement 103 cu. in. (1690 cc)
• Compression Ratio 9.6:1
• Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
• Air Cleaner Fiberglass Media, washable
• Lubrication System Pressurized, dry-sump

Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

Chassis
Frame Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, rectangular tube sections, stamped junctions; MIG welded
Front Forks 49 mm with polished aluminum fork triple clamp and dual-rate springs
Rear Shocks Fully Covered, Coil-over shock
Wheels4: Machined Aluminum Slotted Disc
- Front 16 in. x 3 in. (406 mm x 76 mm)
- Rear 16 in. x 5 in. (406 mm x 127 mm)

Brakes:

• - Caliper Type 4-piston fixed front, and 2-piston torque-free floating rear
• - Rotor Type (diameter x width): Patented, uniform expansion rotors (floating, front only)
• - Front (dual floating) 11.8 in. x .2 in. (300 mm x 5.1 mm)
• - Rear 11.5 in. x .23 in. (292 mm x 5.8 mm)
• - Anti-lock Braking System: Available

Suspension Travel:

• - Front Wheel 5 in. (127 mm)
• - Rear Wheel 2.13 in. (54.102 mm)

Performance
Engine Torque5 (per J1349):

• - North America 100 ft. lbs. @ 3500 RPM (136 Nm @ 3500 RPM)
• Lean Angle (per J1168):
• - Right 30°
• - Left 31°

Fuel Economy6 (EPA urban/highway test) 42 mpg (5.6 L/100 km)

COLOR OPTIONS
Solids
- Vivid Black
- Big Blue Pearl
- H-D Orange
- Black Denim

U.S. MSRP
Vivid Black $15,349
Solids $15,734

Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 40-amp system (493W @ 13.5V, 2000 rpm, 540W max power @ 13.5V)
Starting 1.2 kW electric with solenoid shift starter motor engagement


Lights (as per country regulation):

• - Headlamp (dual quartz halogen) 55-watt low beam, 60-watt high beam
• - Tail/Stop Lights 8W/28W
• - Turn Signal Lights 28W self-canceling
• - Indicator Lamps: High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system7 (optional), 6-speed, low fuel warnings

Read More

Husqvarna TE449, 2011





Husqvarna TE449, 2011



International Specifications
Technical data TE449

General features
Dimensions, weight, capacities
Wheelbase ............................ mm/in. 1490/ 58.66
Overall lenght ....... mm/in. 2280 / 89.76
Overall width ............ mm/in. 820 / 32.28
Overall height ................. mm/in. 1260 / 49.61
Saddle height ............... mm/in. 963 / 37.91
Min. ground clearance ................................. mm/in. 335 / 13.19
Caster angle....................................................................................25.8°
Trail .................................... mm/in. 101 / 3.98
Kerb weight, without fuel ........................... Kg/lb. 113 / 249.12
Fuel tank capacity ....................................... l 8.5
U.S. Gallons 1.93
Imp. Gallons 1.85
Transmission oil ........................................... l 1.15
U.S. Quarts 1.04
Imp. Quarts 1.01

Engine
Characteristics
Type
Single cylinder, four stroke
Bore ..................................... mm/in. 98 / 3.86
Stroke ........................................... mm/in. 59.6 / 2.35
Displacement ........................ cm3/cu.in. 449.6 / 27.44
Compression ratio .......................................................................... 12.0:1
Starting .............................. ELETTRICO / Electric start
Exhaust system ........................ SCARICO COMPLETO IN
Full stainless steel system (silencer and pipes)
Cooling ..................... A LIQUIDO / By liquid
Water radiator .......... N°/No 2

Timing system
Type
"DOHC", 4 valve

Lubrication
Type
Dry sump with two oil pump rotor and cartridge filter
Ignition

Type
C.D.I. electronic, with variable advance (digital control)
Spark plug type ............... "NGK" CR 9EKB
Spark plug gap mm/in 0,7 / 0.0275

Fuel system
Type ...................................................... ad iniezione elettronica /
electronic injection feed
Throttle body .......... KEIHIN D46

Clutch
Type
Wet multiplate type; hydraulic control
Driving disc no .............................................. 6
Driven disc no ................................................... 6
Primary drive
Clutch gear ................ Z/Teeth 22
Torque limiter ....... Z/Teeth 36/20
Primary gear .... Z/Teeth 32
Transmission ratio 2.618

Transmission
Type
Constant mesh gear type
Speed gears no .................................................................. 6
nternal ratios
..................................................................... 1ª/1st 2.286 (32/14)
..................................................................... 2ª/2nd 1.875 (30/16)
..................................................................... 3ª/3rd 1.533 (23/15)
..................................................................... 4ª/4th 1.250 (25/20)
..................................................................... 5ª/5th 1.043 (24/23)
..................................................................... 6ª/6th 0.917 (22/24)

 Secondary drive
Transmission sprocket ................................ Z/Teeth 15
Rear wheel sprocket ................................... Z/Teeth 51
Transmission ratio .......................................................................... 3.40

Driving chain
Manufacturer and type "REGINA" 135 ORN 6-LKS (5/8"x1/4")

Overall ratios
..................................................................... 1ª/1st 20.348
..................................................................... 2ª/2nd 16.689
..................................................................... 3ª/3rd 13.645
..................................................................... 4ª/4th 11.126
..................................................................... 5ª/5th 9.283
..................................................................... 6ª/6th 8.162

Technical data TE449

Frame Type
Double beam and double cradle high resistance Cr/Mo steel (round and elliptical section);
Light alloy rear frame

Front suspension
Type
 "Upside-Down" telescopic hydraulic fork with
advanced axle; compression and rebound stroke adjustment
Ø STELI / Fork legs dia. ............................... mm/in. 48 /1.89
Stroke .......................................................... mm/in. 295 / 11.61
Manufacturer .........................................................................."KAYABA"

Rear suspension
Type
Progressive link with single hydraulic shock absorber; spring preload adjustment, compression (high and low speed) and rebound adjustment
Wheel stroke ......... mm/in. 296 / 11.65
Shock absorber manufacturer ..............................................."KAYABA"

Front brake
Type
Fixed disc, "Wave" type, with hydraulic control and double Ø24 piston floating caliper
Disc dia. ...................................... mm/in 260 / 10.24
Rear brake

Type
Fixed disc, "Wave" type, with hydraulic control and floating Ø26 piston caliper
Disc dia. ...................................... mm/in 240 / 9.45

 Front rim
Material........................... Light alloy
Size ........................................ 1,60"x21"

Rear rim
Material............................ Light alloy
Size ........................................ 2,15"x18"

Front tire
Type.........................................."MICHELIN" Enduro Competition 3
Size ................................................................... 90/90-21"

Rear tire
Type.........................................."MICHELIN" Enduro Competition 3
Size ................................................................. 140/80-18"

Electrical equipment
Voltage .......................................................... 12V
 Lamps wattage
Head light ............................................. 35 / 35 W
Pilot light ...........................................................5 W
Tail light.............."LED" type
Turn signals ...............................................6 W
Battery ................................................................... 12V-6Ah

Read More

Husqvarna TE 310, 2011



Husqvarna TE 310, 2011

General features
Dimensions, weight, capacities
Wheelbase ............................ mm/in. 1470/ 57.87
Overall lenght ....... mm/in. 2260 / 88.98
Overall width ............ mm/in. 820 / 32.28
Overall height ................. mm/in. 1290 / 50.79
Saddle height ............... mm/in. 950 / 37.40
Min. ground clearance ................................. mm/in. 290 / 11.42
Trail .................................... mm/in. 106 / 4.17
Kerb weight, without fuel ........................... Kg/lb. 106 / 233.69
Fuel tank capacity ....................................... l 8.5
U.S. Gallons 1.93
Imp. Gallons 1.87
Transmission oil ........................................... l 0.9
U.S. Quarts 0.95
Imp. Quarts 0.79

Engine Characteristics
Type
Single cylinder, four stroke
Bore ..................................... mm/in. 82 / 3.23
Stroke ........................................... mm/in. 57.35 / 2.26
Displacement ........................ cm3/cu.in. 302.44 / 18.46
Compression ratio ............................................................................. 13:1
Starting .............................. Electric and kick start (with automatic decompressor)
Cooling ..................... By liquid
Water radiator .......... N°/No 2 (With electric fan)

Timing system
Type
INGRANAGGI/4 titanium valves, in a radial arrangement, operated through bowls by two overhead camshafts driven by a combined chain/gears system

Lubrication Type
Dry sump with two oil pump rotor and cartridge filter

Ignition Type
Electronic, inductive discharge, with adjustable advance (digital control)
Spark plug type ............... "NGK" CR 9EB
Spark plug gap mm/in 0,7 / 0.0275

Fuel system
Type ...................................................... electronic injection feed
Throttle body .......... MIKUNI D45

Clutch Type
Wet, multiplate type; hydraulic control
Driving disc no .............................................. 7
Driven disc no ................................................... 6
Primary drive
Engine sprocket ......... Z/Teeth 17
Clutch gear ................ Z/Teeth 54
Transmission ratio 3.176


Transmission Type
Constant mesh gear type
Speed gears no .................................................................. 6
Internal ratios
..................................................................... 1ª/1st 2,142 (30/14)
..................................................................... 2ª/2nd 1,750 (28/16)
..................................................................... 3ª/3rd 1,450 (29/20)
..................................................................... 4ª/4th 1,227 (27/22)
..................................................................... 5ª/5th 1,041 (25/24)
..................................................................... 6ª/6th 0,884 (22/27)
Secondary drive
Transmission sprocket ................................ Z/Teeth 13
Rear wheel sprocket ................................... Z/Teeth 40
Transmission ratio .......................................................................... 3,076
Driving chain
Manufacturer and type "D.I.D." 520 V6-OR/ "REGINA" 135 ORC6-OOC (5/8"x1/4")

Overall ratios
..................................................................... 1ª/1st 20,944
..................................................................... 2ª/2nd 17,104
..................................................................... 3ª/3rd 14,172
..................................................................... 4ª/4th 11,995
..................................................................... 5ª/5th 10,181
..................................................................... 6ª/6th 7,964

Read More

Ducati Monster 1100S, 2011, Motorcycle Accident Lawyer Information



Ducati Monster 1100S, 2011

North American Specifications
USA MSRP - $13,995 USD

Chassis

• FRAME Tubular steel Trellis frame
• WHEELBASE 1450mm (57.1in)
• RAKE 24°
• FRONT SUSPENSION Öhlins 43mm fully adjustable upside-down forks with TiN
• FRONT WHEEL TRAVEL 130mm (5.1in)
• FRONT WHEEL Y-shaped, 5-spoke in light alloy 3.50 x17
• FRONT TYRE Pirelli Diablo Rosso Corsa 120/70 17"
• REAR SUSPENSION Progressive with preload and rebound Öhlins adjustable monoshock
• REAR WHEEL TRAVEL 148mm (5.8in)
• REAR WHEEL Y-shaped, 5-spoke in light alloy 5.50 x 17
• REAR TYRE Pirelli Diablo Rosso Corsa 180/55 17"
• FRONT BRAKE 2 x 320mm discs, 4-piston radial caliper
• REAR BRAKE 245mm disc, 2-piston caliper
• FUEL TANK CAPACITY 15l - 3.8 gallon (US) / 13.5l - 3.6 gallon (US) ABS version
• DRY WEIGHT 168kg (370lb) / 170kg (374lb) ABS version

INSTRUMENTS
Digital unit displaying: Speedometer, rev counter, clock, scheduled maintenance warning, oil temperature, trip fuel, lap time, warning light for low oil pressure, fuel level, fuel reserve, neutral, turn signals, overrev, immobilizer. Ready for DDA system
WARRANTY 2 years unlimited mileage

BODY COLOUR (FRAME/WHEEL)
Red (red / racing gold) - Pearl white (matt black / racing gold)
VERSIONS Dual seat
SEAT HEIGHT 810mm (31.9in)

Engine

• TYPE L-Twin cylinder, 2 valve per cylinder Desmodromic, air cooled
• DISPLACEMENT 1078cc
• BORE X STROKE 98x71.5mm
• COMPRESSION RATIO 10.7:1
• POWER 69.8kW - 95hp @ 7500rpm
• TORQUE 10.5kgm - 75.9lb-ft @ 6000rpm
• FUEL INJECTION Siemens electronic fuel injection, 45mm throttle body
• EXHAUST 2 aluminum mufflers

Transmission
GEARBOX 6 speed
RATIO 1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28

PRIMARY DRIVE
Straight cut gears, Ratio 1.84:1

FINAL DRIVE
Chain; Front sprocket 15; Rear sprocket 39
CLUTCH
Dry multiplate with hydraulic control

Features and Benefits
Monster ABS
The 2011 Monster family now offers all models with optional anti-lock braking system (ABS).
The ABS developed by Ducati and offered as an option on the entire Monster family is the most
sophisticated version available in motorcycling. Designed to reduce the risk of wheel-lock under heavy
braking or when braking in low grip conditions, the system reads wheel speed data from phonic wheel
sensors to detect potential wheel lock. If the wheel speed differential falls below a specific safety limit, the control unit immediately reduces the brake system pressure to the appropriate calliper to avoid wheel lock.

The pressure reduction on each individual braking circuit is activated by electronically controlled valves, which then close as the wheel speed differential moves away from a locking scenario.

Monster frame
An immensely strong but light tubular steel Trellis frame with aluminium rear sub-frame is the visual and
structural backbone of all the Monsters. Delivering unparalleled rigidity with minimal mass, the frame
design is pure Ducati in its ingenuity and simplicity and also enables a very useful 64 degrees of lock-to-lock steering travel. The brand new lightweight aluminium sub-frame maintains visual continuity with the aluminium footrest hangers and swingarm, and is designed to accept a passenger-friendly grab-rail kit available from Ducati Performance. The kit further enhances passenger ride comfort without compromising the Monster’s stylish lines.

Monster instrumentation
Looking clean and minimalist in true Monster style, the brightly illuminated display provides all essential
data by default, and even more by scrolling with the left-hand switchgear. Data includes speed, revs, time, scheduled maintenance, oil temperature and battery voltage, while warning lights illuminate for oil pressure, fuel reserve, turn indicators, high beam and neutral selection. In addition, the instruments present a reserve fuel trip, immobiliser status and automatic light-off function after 60 seconds with the key on as well as a memory to store lap times recorded by using the high-beam flash button as a stopwatch.

The display also doubles as a control panel for the activation of the Ducati Data Analyser (DDA) system, which is available as an accessory from Ducati Performance. All Monsters are built ‘system-ready’ for the data acquisition kit, which consists of a special DDA software and memory key that slots into USB style plug under the seat. The same plug also doubles as the connection for a handy ‘battery maintainer’ available as an accessory from Ducati Performance.

___________________________________________________________________

Motorcycle Accident Lawyer Information
Richard A. Fisher
A Law Corporation
www.rfisherlaw.com

Motorcycle Accidents
Southern California motorcycle accident attorney Richard A. Fisher has been helping victims of Southern California motorcycle accidents for over thirty-five years. Our experience in handling these cases is supported by the many clients we have helped to obtain proper medical treatment and compensation due to injuries sustained from a motorcycle accident.

Types of motorcycle accidents
Whatever your experience has been in driving a motorcycle, many types of accidents involving motorcycles are common in Southern California. At the Law Offices of Richard A. Fisher, our first priority is to assess your case in detail so we can determine the type of accident you have been involved in. Whether you were rear-ended, had a left-turn collision, were involved with a drunk driver, hit from the side, etc., we can effectively help you get back on your motorcycle and retain compensation for your injuries.

Issues relating to motorcycle accidents
A motorcycle accident is very different from an auto accident. There are several different types of injuries that you can sustain from a motorcycle accident. While the types of injuries vary greatly, serious injuries can include: a brain injury, bodily injuries, a ruptured disc or even wrongful death. Our practice specializes in helping victims of motorcycle accidents recover the maximum damages allowable under the law for your case, from sprain and strain to catastrophic injuries.

Successful cases
The Law Offices of Richard A. Fisher has successfully handled hundreds of auto accident cases throughout Southern California. Some recent cases include:

= Motorcycle Accident (Riverside, California): Intersection Accident involving motorcyclist and automobile. Recovery: $320,000

= Motorcycle Accident: Woman passenger on motorcycle, when involved in a single vehicle accident. Sustained multiple fractures to leg requiring insertion of plate and fracture of scapula. Recovery: $250.000 policy limits

= Motorcycle Accident (Los Angeles, California): Intersection Accident involving motorcyclist and automobile. No witnesses - dispute as to who ran the red light. Recovery: $500,000

Read More

Ducati Monster 1100, 2011, Florida Motorcycle Accident Attorney



Ducati Monster 1100, 2011

North American Specifications
USA MSRP - $11,995 USD

Chassis

• FRAME Tubular steel Trellis frame
• WHEELBASE 1450mm (57.1in)
• RAKE 24°
• FRONT SUSPENSION Showa 43mm fully adjustable upside-down forks.
• FRONT WHEEL TRAVEL 130mm (5.1in)
• FRONT WHEEL Y-shaped, 5-spoke in light alloy 3.50 x17
• FRONT TYRE Pirelli Diablo Rosso 120/70 17"

REAR SUSPENSION

• Progressive with preload and rebound Sachs adjustable monoshock
• REAR WHEEL TRAVEL 148mm (5.8in)
• REAR WHEEL Y-shaped, 5-spoke in light alloy 5.50 x 17
• REAR TYRE Pirelli Diablo Rosso 180/55 17"
• FRONT BRAKE 2 x 320mm discs, 4-piston radial caliper
• REAR BRAKE 245mm disc, 2-piston caliper
• FUEL TANK CAPACITY 15l - 3.8 gallon (US) 13.5l - 3.6gallon (US) ABS version
• DRY WEIGHT 169kg (373lb) / 171kg (377lb) ABS version

INSTRUMENTS
Digital unit displaying: Speedometer, rev counter, clock, scheduled maintenance warning, oil temperature, trip fuel, lap time, warning light for low oil pressure, fuel level, fuel reserve, neutral, turn signals, overrev, immobilizer. Ready for DDA system.
WARRANTY 2 years unlimited mileage

BODY COLOUR (FRAME/WHEEL)
Red (red / silver) - Silver (red / silver) - Black (matt black / silver)

VERSIONS
Dual seat
SEAT HEIGHT 810mm (31.9in)

Engine

• TYPE L-Twin cylinder, 2 valve per cylinder Desmodromic, air cooled
• DISPLACEMENT 1078cc
• BORE X STROKE 98x71.5mm
• COMPRESSION RATIO 10.7:1
• POWER 69.8 kW - 95hp @ 7500rpm
• TORQUE 10.5kgm - 75,9lb-ft @ 6000rpm
• FUEL INJECTION Siemens electronic fuel injection, 45mm throttle body
• EXHAUST 2 aluminum mufflers

Transmission
GEARBOX 6 speed
RATIO 1st 37/15, 2nd 30/17, 3rd 27/20, 4th 24/22, 5th 23/24, 6th 24/28
PRIMARY DRIVE Straight cut gears, Ratio 1.84:1

FINAL DRIVE
Chain; Front sprocket 15; Rear sprocket 39
CLUTCH
Dry multiplate with hydraulic control

Features and Benefits
Monster ABS
The 2011 Monster family now offers all models with optional anti-lock braking system (ABS).
The ABS developed by Ducati and offered as an option on the entire Monster family is the most
sophisticated version available in motorcycling. Designed to reduce the risk of wheel-lock under heavy
braking or when braking in low grip conditions, the system reads wheel speed data from phonic wheel
sensors to detect potential wheel lock. If the wheel speed differential falls below a specific safety limit, the control unit immediately reduces the brake system pressure to the appropriate calliper to avoid wheel lock.

The pressure reduction on each individual braking circuit is activated by electronically controlled valves, which then close as the wheel speed differential moves away from a locking scenario.

Monster frame
An immensely strong but light tubular steel Trellis frame with aluminium rear sub-frame is the visual and
structural backbone of all the Monsters. Delivering unparalleled rigidity with minimal mass, the frame
design is pure Ducati in its ingenuity and simplicity and also enables a very useful 64 degrees of lock-to-lock steering travel. The brand new lightweight aluminium sub-frame maintains visual continuity with the aluminium footrest hangers and swingarm, and is designed to accept a passenger-friendly grab-rail kit available from Ducati Performance. The kit further enhances passenger ride comfort without compromising the Monster’s stylish lines.

Monster instrumentation
Looking clean and minimalist in true Monster style, the brightly illuminated display provides all essential
data by default, and even more by scrolling with the left-hand switchgear. Data includes speed, revs, time, scheduled maintenance, oil temperature and battery voltage, while warning lights illuminate for oil pressure, fuel reserve, turn indicators, high beam and neutral selection. In addition, the instruments present a reserve fuel trip, immobiliser status and automatic light-off function after 60 seconds with the key on as well as a memory to store lap times recorded by using the high-beam flash button as a stopwatch.

The display also doubles as a control panel for the activation of the Ducati Data Analyser (DDA) system, which is available as an accessory from Ducati Performance. All Monsters are built ‘system-ready’ for the data acquisition kit, which consists of a special DDA software and memory key that slots into USB style plug under the seat. The same plug also doubles as the connection for a handy ‘battery maintainer’ available as an accessory from Ducati Performance.

 ____________________________________________________________________

Florida Motorcycle Accident Attorney
http://www.theinjurylawyers.com/

Florida motorcycle accident statistics show that motorcycle accidents typically account for a disproportionately high number of catastrophic traffic accidents resulting in brain injury, broken bones, paralysis, and death. Tragically, the vast majority of Florida motorcycle accidents were unavoidable by the motorcyclist who was injured or killed but could have been easily avoided by the other vehicle driver who caused it. The experienced personal injury attorneys at Abrahamson & Uiterwyk understand the complex aspects of Florida motorcycle accident cases, including:

    Florida vehicle laws pertaining to motorcyclists
    Motorcycle accident reconstruction
    Roadway design and architecture as it relates to motorcyclists
    Motorcycle design and manufacturing issues (resulting in product liability)

In most motorcycle-motor vehicle accidents, a negligent or inattentive automobile driver is at fault. Some of the common types of collisions include:

    A driver swerving directly in front of a motorcyclist
    A driver pulling out of an intersection or driveway into the path of an oncoming motorcycle
    A driver's failure to follow posted traffic laws or yield proper right of way
    A driver's failure to see a motorcyclist when changing lanes or passing other motor vehicles
    A driver who is temporarily impaired by drugs or alcohol

If you have questions or concerns about injuries sustained in a motorcycle crash, please contact the Florida motorcycle accident lawyers at Abrahamson & Uiterwyk today. We offer free initial consultations and work on a contingent fee basis, which means that there are no fees or costs unless we win.

For assistance on your Florida motorcycle accident case, call us toll-free at 1-800-753-5203.

_______________________________________________________________

Read More

Harley-Davidson FXDC Dyna Super Glide Custom, 2012



Harley-Davidson FXDC Dyna Super Glide Custom, 2012

NEW  Security Package bundling Anti-lock Braking System (ABS) and a Smart Security System for greater value

NEW Paint color options - Michelin® Scorcher tires

• - Black powertrain with chrome covers
• - Chrome exhaust with dual staggered shorty mufflers
• - 5-gallon Super Glide Custom fuel tank
• - Chrome Steel Laced wheels
• - Low profile front fender
• - Sport wrap-around rear fender with painted supports
• - One-piece, two-up Dyna classic seat
• - Stainless steel, mini pull-back handlebar
• - Chrome low-profile tank console with electronic speedometer

Features and Benefits

• - Rubber-mounted Twin Cam 96 V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI), rated at 92 ft. lbs. of torque
• - 6-speed Cruise Drive® transmission
• - Exposed under-seat battery box
• - Exposed rear coil-over shock absorbers
• - Mid-mounted rider footpegs with brake and shift levers
• - Optional Harley-Davidson® Smart Security System with hands-free security fob and Anti-lock Braking System (ABS)
• - Optional Chrome Aluminum Profile laced wheels
• - Optional Original Equipment Custom Color paint program

USA Specifications/Technical Details
US MSRP Price: Vivid Black $12,999, Solids $13,384, Two-Tones $13,704, Custom Colors $13,874 USD

Dimensions
Length 92.9 in. (2360 mm)
Overall Width 38.9 in. (988 mm)
Overall Height 48.5 in. (1232 mm)
Seat Height:
- Laden2 26.3 in. (668 mm)
- Unladen 26.5 in. (673 mm)
Ground Clearance 4.6 in. (117 mm)
Rake (steering head) 29°
Fork Angle 29°
Trail 4.7 in. (119 mm)
Wheelbase 64.2 in. (1631 mm)
Tires (Michelin® Scorcher® “31” front and rear):
- Front – Scorcher® “31” 100/90-19 57H
- Rear – Scorcher® “31” 160/70-17 73V
Fuel Capacity 5.0 gal. (18.9 L) (warning light at approximately 0.9 gal.)
Oil Capacity (w/filter) 3.0 qts. (2.8 L)
Transmission Capacity 1.0 qt. (.95 L)
Primary Chain
Case Capacity3 1.0 qt. (.95 L)

Weight:
- As Shipped 648 lbs. (294.0 kg)
- In Running Order 679 lbs. (308.0 kg)
- Gross Vehicle Weight Rating 1085 lbs. (492.2 kg)
- Gross Axle Weight Rating:
- Front 390 lbs. (176.9 kg)
- Rear 695 lbs. (315.3 kg)

Engine

• Engine Air-cooled, Twin Cam 96™
• Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
• Bore x Stroke 3.75 in. x 4.38 in. (95.3 mm x 111.3 mm)
• Displacement 96 cu. in. (1584 cc)
• Compression Ratio 9.2:1
• Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
• Air Cleaner Fiberglass Media, washable
• Lubrication System Pressurized, dry-sump

Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

Chassis
Frame Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, rectangular tube sections, stamped junctions; MIG welded
Front Forks 49 mm with polished aluminum fork triple clamp and dual-rate springs
Rear Shocks Coil-over shock
Wheels4 (Chrome Aluminum Profile Laced, front and rear option): Steel Laced
- Front 19 in. x 2.5 in. (483 mm x 64 mm)
- Rear 17 in. x 4.5 in. (432 mm x 114 mm)

Brakes:

• - Caliper Type 4-piston fixed front, and 2-piston torque-free floating rear
• - Rotor Type (diameter x width): Patented, uniform expansion rotors (floating, front only)
• - Front (floating) 11.8 in. x .2 in. (300 mm x 5.1 mm)
• - Rear 11.5 in. x .23 in. (292 mm x 5.8 mm)
• - Anti-lock Braking System: Available

Suspension Travel:

• - Front Wheel 5 in. (127 mm)
• - Rear Wheel 3.1 in. (78.74 mm)

Performance
= Engine Torque5 (per J1349):
   - North America 92 ft. lbs. @ 3000 RPM (125 Nm @ 3000 RPM)
= Lean Angle (per J1168):
   - Right 29.5°
   - Left 30.9°
= Fuel Economy6 (EPA urban/highway test) 43 mpg (5.5 L/100 km)

Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 40-amp system (493W @ 13.5V, 2000 rpm, 540W max power @ 13.5V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Tail/Stop Lights 8W/28W
- Turn Signal Lights 28W self-canceling
- Indicator Lamps: High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system7 (optional), 6-speed, low fuel warnings

Read More

Harley-Davidson FXDB Dyna Street Bob, 2012



Harley-Davidson FXDB Dyna Street Bob Model Highlights, 2012

NEW Optional Security Package bundling Anti-lock Braking System (ABS) and a Smart Security System for greater value
- Michelin® Scorcher tires
- All-black powertrain
- Tank medallion
- Chrome exhaust with dual straight-cut staggered shorty mufflers
- 4.7-gallon Street Bob fuel tank
- Black Steel Laced wheels
- Chopped rear fender without support covers
- Solo seat
- Stainless steel, internally-wired mini ape-hanger handlebar
- Top triple clamp with integrated riser
- Wrinkle-black low-profile tank console with electronic speedometer
- Wrinkle-black battery box and belt guard
- Retro-style LED tail light
- Street Bob air-cleaner trim ring

Features and Benefits
- Rubber-mounted Twin Cam 96™ V-Twin engine with Electronic Sequential Port Fuel Injection (ESPFI), rated at 92 ft. lbs. of torque
- 6-speed Cruise Drive® transmission
- Exposed under-seat battery box
- Exposed rear coil-over shock absorbers
- Mid-mounted rider footpegs with brake and shift levers
- Optional Harley-Davidson® Smart Security System with hands-free security fob and Anti-lock Braking System (ABS)

USA Specifications/Technical Details
US MSRP Price: Vivid Black $14,259, Color Option $14,679, Security Package (Security and ABS) $1,310 CDN

Dimensions
Length 92.8 in. (2357 mm)
Overall Width 37.5 in. (953 mm)
Overall Height 50.4 in. (1280 mm)
Seat Height:
- Laden2 25.5 in. (648 mm)
- Unladen 26.7 in. (678 mm)
Ground Clearance 4.92 in. (125 mm)
Rake (steering head) 29°
Fork Angle 29°
Trail 4.7 in. (119 mm)
Wheelbase 64.2 in. (1631 mm)
Tires (Michelin® Scorcher® “31” front and rear):
- Front – Scorcher® “31” 100/90-19 57H
- Rear – Scorcher® “31” 160/70-17 73V
Fuel Capacity 4.7 gal. (17.8 L) (warning light at approximately 0.9 gal.)
Oil Capacity (w/filter) 3.0 qts. (2.8 L)
Transmission Capacity 1.0 qt. (.95 L)
Primary Chain
Case Capacity 1.0 qt. (.95 L)

Weight:
- As Shipped 637 lbs. (289.0 kg)
- In Running Order 670 lbs. (304.0 kg)
- Gross Vehicle Weight Rating 1085 lbs. (492.2 kg)
- Gross Axle Weight Rating:
- Front 390 lbs. (176.9 kg)
- Rear 695 lbs. (315.3 kg)

Engine
Engine Air-cooled, Twin Cam 96
Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder
Bore x Stroke 3.75 in. x 4.38 in. (95.3 mm x 111.3 mm)
Displacement 96 cu. in. (1584 cc)
Compression Ratio 9.2:1
Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
Air Cleaner Fiberglass Media, washable
Lubrication System Pressurized, dry-sump

Drivetrain
Primary Drive Chain, 34/46 ratio
Final Drive Belt, 32/66 ratio
Clutch Multi-plate, wet
Transmission 6-Speed Cruise Drive®
Gear Ratios (overall): U.S.
- 1st 9.311
- 2nd 6.454
- 3rd 4.793
- 4th 3.882
- 5th 3.307
- 6th 2.79

Chassis
Frame Mild steel, tubular frame; rectangular section backbone; stamped, cast, and forged junctions; forged fender supports; MIG welded
Swingarm Mild steel, rectangular tube sections, stamped junctions; MIG welded
Front Forks 49 mm with polished aluminum fork triple clamp and dual-rate springs
Rear Shocks Coil-over shock

Wheels4: Black Steel Laced
- Front 19 in. x 2.5 in. (483 mm x 64 mm)
- Rear 17 in. x 4.5 in. (432 mm x 114 mm)

Brakes:
- Caliper Type 4-piston fixed front, and 2-piston torque-free floating rear
- Rotor Type (diameter x width): Patented, uniform expansion rotors (floating, front only)
- Front (floating) 11.8 in. x .2 in. (300 mm x 5.1 mm)
- Rear 11.5 in. x .23 in. (292 mm x 5.8 mm)
- Anti-lock Braking System: Available

Suspension Travel:
- Front Wheel 5 in. (127 mm)
- Rear Wheel 3.1 in. (78.74 mm)

Performance
Engine Torque5 (per J1349):
- North America 92 ft. lbs. @ 3000 RPM (125 Nm @ 3000 RPM)
Lean Angle (per J1168):
- Right 30°
- Left 31°

Fuel Economy6 (EPA urban/highway test) 43 mpg (5.5 L/100 km)

Electric
Battery (per Battery Council International Rating)
Sealed, maintenance-free, 12V, 19-amp/hour, 270 cca
Charging Three-phase, 40-amp system (493W @ 13.5V, 2000 rpm, 540W max power @ 13.5V)
Starting 1.2 kW electric with solenoid shift starter motor engagement
Lights (as per country regulation):
- Headlamp (quartz halogen) 55-watt low beam, 60-watt high beam
- Rear Turn Signal Lights 9W/43W self-canceling
- Indicator Lamps: High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system7 (optional), 6-speed, low fuel warnings

Read More
